Capacitance Proximity Sensor Switch NPN NC DC 6-36V 300mA M18 3-Wire V6587
Capacitance Proximity Sensor Switch NPN NC DC 6-36V 300mA M18 3-Wire V6587
Product Name : Capacitive Proximity Switch; Model : LJC18A3-H-Z/AX; Wire Type : DC 3 Wire Type (Brown, Black, Blue);Switch Appearance Type : Cylinder Type Theory : Capacitance Sensor; Output Type : NPN NC(Normally closed);Diameter of Head : 18mm;Detecting Distance : 1-10mm Detecting Object : Metal or Nonmetal Material; Supply Voltage : DC 6-36V;Current Output : 300mA;Response Frequency : 100Hz Operating Temperature : -25 to +65 Celsius (Non-freezing Condition);Size : 7.5 x 3cm / 3'x 1.2'(L*Max.
Theory : Capacitance Sensor; Output Type : NPN NC(Normally closed);Diameter of Head : 16mm; Thread Diameter:18mm; Detecting Distance : 1-10mm
Detecting Object : Metal or Nonmetal Material; Supply Voltage : DC 6-36V;Current Output : 300mA;Response Frequency : 100Hz
Operating Temperature : -25 to +65 Celsius (Non-freezing Condition);Size : 7.5 x 3cm / 3'x 1.2'(L*Max. Dia);Cable Length : 120cm/47';External Material : Plastic, Alloy
Net Weight : 85g;Color : Silver Tone, blue, Gray; Package Content : 1 x Capacitive Proximity Switch
It is a component widely used in automatic control industry for detecting, controlling, and noncontact switching. When proximity switch is close to some target object, it will send out control signal. As it is capacitive type proximity switch, its detecting object target is not limited to only conductor, but also liquid and even powder things, like plastic, water, glass, oil, etc. It's widely used in machine, paper making, light industry for limiting station, orientation taking count, speeding trial ect. Product Name : Capacitive Proximity Switch;Switch Appearance Type : Cylinder Type Theory : Capacitance Sensor;Output Type : NPN NC(Normally closed);Diameter of Head : 18mm;Detecting Distance : 1-10mm Detecting Object : Metal or Nonmetal Material;Supply Voltage : DC 6-36V;Current Output : 300mA;Response Frequency : 100Hz Size : 7.5 x 4cm/3'' x 1.6'' (L*Max. Dia);Material : Plastic, Alloy
